2023 JCB 1CX Backhoe and Front Loader With Skid Steer for Sale With High Efficiency Mini Wheel in USA
2023 JCB 1CX Backhoe and Front Loader With Skid Steer for Sale With High Efficiency Mini Wheel in USA
The JCB 1CX Backhoe Loader is a powerful and versatile machine designed for various construction and excavation tasks. With a backhoe dig depth of 8.4 feet and a loader lift capacity of 1345 pounds, this compact equipment offers impressive capabilities in a small package. The 50 horsepower engine, efficient hydraulics system, and intuitive controls make it easy to operate while delivering excellent performance on the job site. Additionally, the durable construction and convenient features of the JCB 1CX ensure a productive and reliable experience for operators in various working conditions.
General Specifications
Backhoe
| Dig Depth |
8 ft (3 m) |
| Loading Height |
8 ft (2 m) |
| Max dig depth |
8 ft (3 m) |
| Max Digging Depth |
8 ft (3 m) |
| Reach From Swivel |
11 ft (3 m) |
Capacities
| Cooling system |
2 gal (8 l) |
| Engine oil with filter |
3 gal (10 l) |
| Fuel Tank |
12 gal (45 l) |
Dimensions
| Ground Clearance |
1 ft (0 m) |
| Height to Top of Suspended Cab |
7 ft (2 m) |
| Transport Length |
11 ft (3 m) |
| Transport Width |
5 ft (1 m) |
| Wheelbase |
4 ft (1 m) |
Electrical System
| Alternator |
50 |
| Battery |
72A/hour |
| Front working lights |
2 adjustable |
| Gauges |
Fuel Level Hour meter |
| Pre-wire |
Beacon |
| Rear working lights |
2 adjustable |
Engine
| Aspiration |
Natural |
| Displacement |
134 cu in (2,201 cu cm) |
| Emissions Certification |
Stage EC Stage IIIA |
| Engine Model |
104-22 |
| Fuel Type |
Replaceable cartridge plus water/sediment separator prefilter |
| Gross Power |
50 hp (37 kw) |
| Net Max Torque |
100 lbs ft (135 nm) |
| Net Power |
47 hp (35 kw) |
| Number of Cylinders |
4 |
| Power Measured @ |
2800 rpm |
| Rated engine speed |
2800 rpm |
| Torque Measured @ |
2000 rpm |
Hydraulic System
| Pump Flow Capacity |
12 gpm (45 lpm) |
| Relief Valve Pressure |
3000 psi |
Loader
| Breakout Force |
5,179 lbs (2,349 kg) |
| Bucket Breakout Force |
5,179 lbs (2,349 kg) |
| Bucket Width |
56 in (143 cm) |
| Clearance at Max Dump Height |
7 ft (2 m) |
| Dig Depth |
2 in (5 cm) |
| Dump height |
7 ft (2 m) |
| Lift Capacity |
1,345 lbs (610 kg) |
| Load over height |
8 ft (3 m) |
| Reach at Max Dump Height |
1 ft (0 m) |
| SAE – Net |
47 hp (35 kw) |
Operating Specifications
| Cooling System Fluid Capacity |
2 gal (8 l) |
| Fuel Capacity |
12 gal (45 l) |
| Hydraulic System Fluid Capacity |
12 gal (45 l) |
| Oil System Fluid Capacity |
1 gal (5 l) |
| Operating Voltage |
12 volts |
| Operating Weight |
6,150 lbs (2,790 kg) |
| Operating Weight 4wd |
6,150 lbs (2,790 kg) |
| Tire Size Front – 2wd / 4wd |
7×15 |
Tires
Transmission
| Max Speed |
7 mph (11 kph) |
| Max Speed – Reverse |
7 mph (11 kph) |
| Number of Forward Gears |
1 |
| Number of Reverse Gears |
1 |
| Transmission Type |
Hydrostatic |
Travel Speed
| 4Th Gear Fwd |
7 mph (11 kph) |
