The 2025 John Deer 4066R is the flagship model of the 4R series. It is a premium compact utility tractor designed for heavy-duty tasks where a high power-to-weight ratio is required. It is notably a “No-DEF” machine, meeting Tier 4 Final standards using only a Diesel Particulate Filter (DPF).¹

Below are the direct technical specifications for the 2025 model:

Engine & Power

• Engine: Yanmar 4TNV86CHT-MJT, 4-Cylinder, Turbocharged Diesel²



• Displacement: 127.6 cu. in.³ (2.09 L)



• Gross Horsepower: 65.9 HP @ 2,600 RPM⁴



• PTO Horsepower: * eHydro: 52.0 HP⁵



  • PowrReverser: 54.0 HP⁶



• Emissions: Final Tier 4 (FT4) / Stage V (No DEF required)⁷



• Engine Torque: 131.3 lb-ft at rated speed⁸



• Fuel Capacity: 13.8 gal (Cab) / 15.0 gal (ROPS)⁹



Transmission & Drivetrain

• Standard Transmission: eHydro™ (3-Range Electronic Hydrostatic) with Twin Touch™ pedals.¹⁰



• Optional Transmission: 12F/12R PowrReverser™ (Mechanical shuttle).¹¹



• eHydro Controls: Includes LoadMatch (anti-stall), MotionMatch (adjustable coasting), SpeedMatch (low-speed cruise), and eThrottle (RPM follows pedal travel).¹²



• Drive Type: 4WD (MFWD) with planetary final drives.¹³



• Brakes: Multi-plate wet disc.¹⁴



Hydraulics & Hitch

• System Type: Open Center, dual gear pump.¹⁵



• Total Pump Output: 17.4 GPM (65.8 L/min)¹⁶



  • Implement Flow: 11.2 GPM (42.3 L/min)¹⁷



  • Steering Flow: 6.2 GPM (23.5 L/min)¹⁸



• 3-Point Hitch: Category 1 (Standard with Hitch Assist for easier hookups).¹⁹



• Lift Capacity (at ends): 3,130 lbs (1,420 kg)²⁰



• Lift Capacity (24″ behind): 2,500 lbs (1,135 kg)²¹



• Remote Valves: 3 standard mid-valves (controlled by joystick); optional rear remotes.

Dimensions & Weight

• Wheelbase: 73 in (185 cm)²²



• Overall Length: ~142 in

• Height (Top of Cab): 97.4 in

• Weight (Approximate Shipping):

  • ROPS (Open Station): 3,770 lbs²³



  • Cab: 4,675 lbs²⁴



• Axle Capacity: 3,528 lbs (Front) / 5,292 lbs (Rear).²⁵



Performance Matched Loader (440R)

• Max Lift Height: 110.2 in (at pivot pin)

• Lift Capacity: 2,285 lbs (at pivot pin)

• Breakout Force: 3,452 lbs
